Brand Name : TuoWei
Model Number : TW-Z3-400T
Place of Origin : China
MOQ : 1group
Price : USD55500-57000/group
Payment Terms : T/T
Supply Ability : 45work days
Delivery Time : 45work days
Packaging Details : simple packaging
colour : white
Type : TWZ400T
Clapping force(TON) : 400
Stroke(MM) : 300
Working Plate Size(MM) : 800*800
Dimeter of cyhnder(MM) : 500
Horse powet(HP) : 15*2
Heater power(KW : 57
Total power(KW) : 83
Gross weight(KG) : 20000
Machine size(MM) : 4000*3000*3000
White Rubber Injection Moulding Machine In And Out Of The Template Heat Treatment
Machine characteristics
Double powers, double oil pumps, double motors and double oil coolers are applied for the two
axles to work independently.
The oil system is unique in design with good stability, faster lift-up and lift-down speed compared
with other brands when unloading/loading mold.
High vacuum and the average pumping method are applied for the manufacturing of stable products
and improving the quality and productivity.
The pedestal vacuum oxygen tank provides large oxygen storage space.The new mold raising
mechanism design has the
advantages of long working life, quiet mold-unloading/loading, fastness and stability.
Applicable products
Auto parts, rubber packing, medical rubber, O ring, key, rubber for civil use, industrial rubber and bottle
stopper, etc.
Type | TWZ400T |
Clapping force(TON) | 400 |
Stroke(MM) | 300 |
Working Plate Size(MM) | up:750*750 down:800*800 |
Dimeter of cyhnder(MM) | 500 |
Horse powet(HP) | 15*2 |
Heater power(KW | 57 |
Total power(KW) | 83 |
Gross weight(KG) | 20000 |
Machine size(MM) | 4000*3000*3000 |
![]() |
400T white vacuum machine 800*800 table 300 stroke hot plate nitriding treatment Images |
